Features
- Output of aerosol with high concentration;
- Larger oil storage space, increased by 40% compare4d to traditional generator
- An external LCD display to read temperature and pressure variations in real time;
- Applicable to different flow rates of air conditioning systems;
- 2-min rapid heating;
- Multiple types of aerosol can be used.
There are no reviews yet.
[contact-form-7 id="752" title="Question & Answer"]
Questions and answers of the customers
There are no questions yet, be the first to ask something for this product.
- Airflow range : 500-70000cfm (833-119000m3/h)
- Concentration range : 10µg/L:flow 70000cfm; 100µg/L:flow 7000cfm
- Heating time : <2-3min, operation temperature to reach 370°C
- Aerosol Reagent : PAO-4, DOS/DEHS, Ondina EL, DOP/DEHP and Mineral Oil
- Generation : Thermal condensation
- Running time : 70min
- Air source : Nitrogen, Argon, Carbon Dioxide or helium(50psi) ; 345kPa±70kPa
- Power source : AC 120-240V 50/60Hz
- Size (L x W x H) : 430x140x350mm
- Weight : around 10kgs
